Qingling Isuzu Giga Tractor Truck VC61 6X4 QL1310U1VDH

Transmission Type: Manual
Power: Diesel
Load Capacity: ＞50t
Emission Standard: Euro 5
Availability:
Quantity:
Inquire Add to Basket

  • QL1310U1VDH

Product Description

New ISUZU VC61 6x4  Tractor Truck (Euro V)


Qingling ISUZU GIGA New Generation Heavy Truck

Features: High end, intelligent, home-based and customized

It has high horsepower, automatic gear, disc brake, etc. to bring more value and meet more requirements of users.

Specification

Heavy Duty Truck：VC 61  Parameter Comparison

Truck name

Tractor

Truck No.

QL1310U1VDH

Engine Model No.

6UZ1-TCG51

Displacement

9839

Engine power

257

Torque

1422

Drive Speed Ratio

Transmission Model

ZF8S2030TO

Gross Mass(kg)

31000

Curb Mass(kg)

12550

Load Mass(kg)

 18320

Towering mass (kg)

39920/40000

Wheel base(mm)

1850+4575+1370mm

Cab type

Single row

Passenger

2

Overall dimension Length (mm)

12000

Overall dimension Width (mm)

2540

Overall dimension Height (mm)

3180

Front wheel track(mm)

2065/2065

Rear wheel track(mm)

1855/1855

Leaf spring

7/ 7/10

Front suspension (mm)

1370

Rear suspension (mm)

2835

Axle load(kg)

6500/18000

Max. speed

110
