Product Description
Qingling ISUZU 4x2 Fence Lorry Stake Truck 100P
QingLing ISUZU 100P fence stake truck is the good partner suitable for agricultural and sideline products transportation and livestock animals transportation.
In the shape design, the truck is designed to be beautiful in appearance, reasonable in internal structure, advanced in technology, high-quality materials as the skeleton, high in strength, and light in weight, easy to install, safe and reliable.
100P new model cabin is adopted front headlight follow-up steering technology, more beautiful, confortable and safe.
ISUZU world-leading 4KH1CN-type brand new diesel engine with fully-electronic precise control and high-pressure common rail is employed, with stronger power, lower oil consumption, better oil adaptability and better low-temperature starting property: The new 4KH1CN engine, in line with the high quality of the ISUZU 4KH1 engine, matches the world-class Bosch diesel all-electronic precision control high-pressure common rail injection system. The system has high injection pressure and can improve the visible pollutant emission of the engine. Multi-injection of electronic injectors, precise and precise injection of diesel fuel to improve engine noise and vibration. Supercharged intercooling technology,SCR Post processing system. The engine has strong power, low fuel consumption, reliable and durable.
Advantages:
• More environmentally friendly
Qingling Guo V products have achieved low emission and low fuel consumption in the whole life cycle. The performance of the whole vehicle has been improved synchronously, with lower noise, less jitter and quieter and more comfortable driving.
• More economical (fuel saving and urea saving)
Low fuel consumption, saving more than 10% - 15% fuel compared with domestic vehicles with the same load capacity;
High precision calibration of urea injection quantity reduces the user's use cost and is convenient for refitting customers;
• High reliability and low maintenance cost.
• Stronger oil adaptability
Taking full account of the use conditions of Chinese oil products and users, the matching development has improved the adaptability to oil products.
• More cost-effective
• In the case that the growth rate of domestic similar national six models is higher than that of overseas five models by more than 10% - 20%, Qingling only increased by 3-4%.
ISUZU CHINA 100P Stake Truck Specifications:
Truck Brand | Isuzu |
Driving Type | Left Hand Drive |
Overall Dimension(L*W*H) | 5995*2160*2960mm |
Box Dimension (L*W*H) | 4250*2030*400mm |
GVW | 4125Kg |
Curb Weight | 2500Kg |
Axle loading: | 1680/2445Kg |
Wheelbase | 3360mm(Optional) |
F/R Track | 1504/1525mm |
Approaching Angle/Departure Angle(o) | 24/16 |
Tire No. | 7(Including Spare Tire) |
Tire | 7.00R16 8PR |
Color: | Optional |
Max Speed(Km/h) | 98Km/h |
Engine | |
Engine System | 4 Stroke, High Pressure Common Rail, Inter-cooling Turbo-Charged, 4 Cylinders |
Model | 4KH1CN5LS |
Fuel Type | Diesel Engine |
Max output | 70Kw |
Horsepower: | 98HP |
Max Torque | 220N.m/1700rpm |
Emission Standard | Euro V |
Displacement: | 2999ml |
Transmission: | |
Model: | MSB-5MT |
Type | Manual |
Forward/Reverse | 5F/1R |
Brake System: | |
Service Brake | Vacuum Boosting Hydraulic brake |
Parking Brake | Drive Shaft Drum Brake |
Auxiliary System | Engine Exhaust Brake |
Cabin | |
Single-Row Cabin with Air Conditioner | |
Other Equipment: | |
Power Steering, ABS, Maintenance Free Battery, Retro-reflective marking |
