QINGLING Refrigerated truck QL5100XLCA8MAJ

Steering place/方向盘位置:

Left hand drive左舵

Driving type/驱动形式

4×2

GVW/总质量

9975kgs

Curb weight/整备质量（kg）

5040kg

Overall Dimension/整车尺寸mm(LxWxH)

8045*2245*3330

Wheelbase/轴距(mm)

4475

Max. Speed/最高车速(km/h)

110km/h

Emission Standard/排放

EURO V/欧五

Rated output power功率

150HP

Transmission/变速箱

Model/型号

MLD-6Q

Suspension/悬架

前8后10+6

Wheels and tires/轮胎

8.25r2014PR

Front track/rear track mm

1680mm/1650mm

Front suspension/rear suspension 前悬/后悬

1110/2460

Axle load kg:

3350/6625

Approach angle/depature angle

12-16

Material of container/冷冻货箱材料

Aluminum/铝材

Cooler/冷冻机组

Japanese Denso SF1/SF2

low temperature single room

Model: SS21LN-S2MN1

Configuration/其他配置

1. Power steering

2. AC

3. Retro-reflective Marking

4. Vacuum tire

5. Air brake

6. Free Maintenance Battery

7. CARRIER S750
