Qingling 8x4 VC61 Heavy Truck Chassis QL1310U1VDH

Condition: New
Steering: Left
Horsepower: 350ps
Fuel Type: Diesel
Drive: 8x4
Emission Standard: Euro V
Overall dimension：11800x2540x3055,3700mm


Availability:
Quantity:
Inquire Add to Basket

  • QL1310U1VDH

Product Description

Qingling 8x4 VC61 Heavy Truck Chassis QL1310U1VDH


vc61 8x4 底盘

Main Specifications:


Model QL1310U1VDHY
Driving type 8x4
Overall dimension (mm) 11800x2540x3055,3700mm
Displacement（ml） 9839
GVW(KG) 31000
Curb weight(KG) 10450/10600
Wheelbase(mm) 1850+4575+1370
Engine Model 6UZ1-TCG51
Engine Power 256Kw/350PS
Transmission ZF8S2030TO
Emission Euro V
Front wheel track (mm) 2065/2065
Rear wheel track(mm) 1855/1855
Axle load（KG） 6500/6500/18000
Max. Speed(km/h) 100
Front/rear suspension（mm） 1370/2835 mm
Tire 315/80R22.5 16PR,12R22.5 16PR
Cabin Single row
Other configurations ABS
power steering
Reflective signage
air conditioning system
Maintenance-free battery
