QINGLING ISUZU FTR 10m³ Water Truck 4x2

Condition: New
Steering: Left
Horsepower: 205hp
Fuel Type: Diesel
Drive: 4x2
Emission Standard: Euro 6
Brand: Isuzu
Chassis size: 6435 x 2530 x 2810mm


Availability:
Quantity:
Inquire Add to Basket

  • QL1180JQFRY

  • ISUZU

Product Description

Qingling ISUZU   205PS  FTR Truck  4x2  QL1180JQFR

Advantages:


• More environmentally friendly

Qingling Guo VI products have achieved low emission and low fuel consumption in the whole life cycle. The performance of the whole vehicle has been improved synchronously, with lower noise, less jitter and quieter and more comfortable driving.


• More economical (fuel saving and urea saving)

Low fuel consumption, saving more than 10% - 15% fuel compared with domestic vehicles with the same load capacity;

High precision calibration of urea injection quantity reduces the user's use cost and is convenient for refitting customers;


• High reliability and low maintenance cost.


• Stronger oil adaptability

Taking full account of the use conditions of Chinese oil products and users, the matching development has improved the adaptability to oil products.


• More cost-effective

• In the case that the growth rate of domestic similar national six models is higher than that of overseas five models by more than 10% - 20%, Qingling only increased by 3-4%.





 QINGLING ISUZU FTR 10m³ Water Truck（Euro 6）


Model：

QL1180JQFRY

Drive：

4×2

Chassis  dimension：

L:6435 / W:2530 / H:2810
Tank volume：

10m³

GVW：

18000KG

Curb mass：

5400KG

Load mass：

 kg

Wheelbase(mm)：

3900 mm

Engine Model：

4HK1-TCG60

Engine power：

151kW/205PS

Fuel type：

Diesel

Emission：

Euro VI

Max. speed：

105km/h

Tire：

295/80R22.5 16PR,295/80R22.5 18PR

Cab：

One row with a berth

Cab allowable passengers：

3
Front wheel track 1960/1990/2030mm
Rear wheel track 1855mm
Axle load 6500/11500KG
Max. speed 105/89  km/h

Other configurations：

ABS

Power steering

Retro-reflective marking

AC

Free-maintenance battery
Tank parameters

10 square water wheel reference size: 8550 * 2500 * 3055mm

Basic configuration of water truck: equipped with front flushing, rear spraying, side spraying, rear work platform, green cannon, self flow valve, fire interface, water level gauge,  2 water pipes, each 3 meters long., ordinary paint, standard Yifeng water pump, manual operation. The tank body is made of carbon steel material, with a cylinder body of 4mm, a head of 5mm, and a partition of 3.5mm;
