Isuzu KV100 Mini Dump Tipper Truck 4x2 with 2-8 Tons Loading

Condition: New
Steering: Left
Horsepower: 115hp
Fuel Type: Diesel
Drive: 4x2
Emission Standard: Euro 5
Brand: Isuzu
Capacity (load):  3-8 Ton

Availability:
Quantity:

Product Description

4x2 Isuzu KV100 Mini Dump Tipper Truck

Generally called a truck, it refers to a car mainly used to transport goods, and sometimes refers to a car that can tow other vehicles, belonging to the category of commercial vehicles. Generally, according to the weight of the car, it can be divided into two types: heavy and light. Most trucks are powered by diesel engines, but some light trucks use gasoline, LPG or natural gas.


kv 100kv100-3



Advantages:


• More environmentally friendly

Qingling Guo V products have achieved low emission and low fuel consumption in the whole life cycle. The performance of the whole vehicle has been improved synchronously, with lower noise, less jitter and quieter and more comfortable driving.


• More economical (fuel saving and urea saving)

Low fuel consumption, saving more than 10% - 15% fuel compared with domestic vehicles with the same load capacity;

High precision calibration of urea injection quantity reduces the user's use cost and is convenient for refitting customers;


• High reliability and low maintenance cost.


• Stronger oil adaptability

Taking full account of the use conditions of Chinese oil products and users, the matching development has improved the adaptability to oil products.


• More cost-effective

• In the case that the growth rate of domestic similar national six models is higher than that of overseas five models by more than 10% - 20%, Qingling only increased by 3-4%.


Isuzu Tipper Truck Specifications

ITEM

UNIT

PARAMETER

Vehicle

ISUZU KV100 dump truck

Overall dimensions

mm

5800×2000×2260

Box dimension

mm

3200x1800x400

GVW

kg

4500

Curb weight

2500

Payload

2000

Wheel base

mm

3360

F/R track base

1385/1395

F/R Suspension

1200/1080

Approach/departure angle

°

20/12

Max speed

km/h

90

Axle Load

kg

2500/4800

Drive model

4x2

Fuel type

Diesel

Tire specification

7.00R16

Number of axles

2

Engine

4KH1CN5MD

Emission/kw

2999ml/85Kw, 115Hp

type

MSB 5F/1R

Rate speed rpm

2900

Max Torque N.M/ rpm

277/1500

Standard Configuration

Tank material Q235

Air condition available

Single row

Left hand driving

Middle lifting system

Bucket side 3mm and bottom 4mm
